How to Secure Your SSH Server with SSHGuard and Port Knocking

Keeping your SSH server safe from brute-force attacks is critical for maintaining server integrity. Two powerful tools — SSHGuard and Port Knocking — can drastically reduce unauthorized access attempts, giving you multiple layers of protection.

In this guide, we’ll walk through setting up both methods on Ubuntu, so you can harden your SSH service against intrusions.

Why Combine SSHGuard and Port Knocking?

Think of SSHGuard as the bouncer at your server’s door — it spots suspicious login attempts and blocks offenders.
Port Knocking is more like a secret handshake — your server only opens the door when it recognizes the correct knock sequence.

By using both, you get:

• Real-time brute-force attack prevention
• Hidden entry points for extra stealth
• Automatic blocking of malicious IPs
• Flexible integration with firewalls (UFW or iptables)

Setting Up SSHGuard

SSHGuard monitors log files for repeated failed login attempts and automatically blocks offending IPs.

1. Install SSHGuard

sudo apt install sshguard

2. Enable and Start the Service

sudo systemctl enable --now sshguard.service

3. Configure SSHGuard

Edit the configuration file:

sudo nano /etc/sshguard/sshguard.conf

Key parameters:

• BACKEND — Firewall backend (sshg-fw-nft-sets for nftables, sshg-fw-iptables for iptables).
• LOGREADER — How logs are processed.
• THRESHOLD — Failed attempts before blocking an IP.
• BLOCK_TIME — Duration of the block (seconds).
• DETECTION_TIME — Time window to track failed attempts.
• WHITELIST_FILE — Path to trusted IP addresses that are never blocked.

Restart SSHGuard after changes:

sudo systemctl restart sshguard

Integrating SSHGuard with Firewalls

Option 1: SSHGuard + UFW

1. Set the backend:

/usr/libexec/sshguard/sshg-fw-nft-sets

2. Edit UFW rules:

sudo nano /etc/ufw/before.rules

Add:

-A ufw-before-input -j SSHGUARD
-A ufw-before-output -j SSHGUARD
-A ufw-before-forward -j SSHGUARD

3. Restart UFW:

sudo systemctl restart ufw

Option 2: SSHGuard + iptables

1. Create a chain:

sudo iptables -N sshguard

2. Redirect SSH traffic:

sudo iptables -A INPUT -p tcp --dport 22 -j sshguard

3. Save rules:

sudo apt install iptables-persistent
sudo iptables-save -f /etc/iptables/rules.v4

4. View blocked IPs:

sudo iptables -L sshguard -n

Whitelisting Trusted IPs

Add safe IP addresses to:

/etc/sshguard/whitelist

Example:

192.168.0.34
192.168.0.0/24
myhost.domain.com

Then restart SSHGuard:

sudo systemctl restart sshguard

Setting Up Port Knocking

Port Knocking adds another layer by keeping your SSH port closed until a specific sequence of port hits is received.

1. Install knockd

sudo apt install knock-server

2. Manage the Service

sudo systemctl start knockd
sudo systemctl enable knockd

3. Prepare Firewall Rules

Allow existing connections:

iptables -A INPUT -i <interface> -m state --state ESTABLISHED,RELATED -j ACCEPT

Block new ones by default:

iptables -A INPUT -j DROP

4. Configure knockd

Edit:

sudo nano /etc/knockd.conf

Example:

[options]
logfile = /var/log/knockd.log
interface = eth0

[openSSH]
sequence = 661,671,681
seq_timeout = 5
tcpflags = syn
cmd_timeout = 30
start_command = /sbin/iptables -I INPUT -i eth0 -s %IP% -p tcp --dport 22 -j ACCEPT
stop_command = /sbin/iptables -D INPUT -i eth0 -s %IP% -p tcp --dport 22 -j ACCEPT

Restart knockd:

sudo systemctl restart knockd

Connecting with Port Knocking

From your client:

knock target.host 661 671 681
ssh user@target.host

If the sequence matches, your SSH port will temporarily open.

Final Thoughts

By combining SSHGuard and Port Knocking, you create a layered defense:

• Attackers can’t brute-force SSH because repeated failures get them banned.
• They won’t even see the SSH port unless they know the exact knock sequence.

🔐 Security Tip:
Always pair these tools with strong SSH keys, disabled root login, and updated firewall rules.

Ready to lock down your SSH server? Start with SSHGuard, add Port Knocking, and sleep better knowing your server’s doors are truly guarded.
